MK4 Drive Box Controller: Variable Speed Operation

Features
Software Specification
small screen: turn horizontally for a better display

FEATURES:

The Standard configuration comes with:

Processors: 1 each IntelTM i7
Processors: 1 each Intel™ i5 Haswell
Monitors: 1 each 10" TFT Active Capacitive Touch
Macro buttons: 4 dedicated
Hold-To-Run: Active at all times
Joysticks: 2 paddle style, assignable to variety of commands
Emergency Stop System Controls: Active integrated controls for RESET
System Alarm: Configurable Audible and Visual
Included Accessories: Carry/Storage Case with protective foam insert
USB Ports: 2 external
Network Ports: 2 each for NETA & B
Power Source: Universal Power Supply with isolation 90-230V 50/60Hz
Dimensions & Weight: 15"W x 11. 75"H x 5.25"D (381 x 299 x 140mm), 6.2Ibs / 2.8kg
Colour: RAL7021 black Gray

SHOWSDT | Automation | Micro+G2 motion automation console

AUTOMATION CONSOLE SOFTWARE
The IMPERIUM & The Micro+G2 run the acclaimed Raynok Software in a compact and feature rich package.
Make it simple, customize the layout with buttons or lists, create flashing macros, access all machinery at once, or focus on a single hoist, configure constraints and interlocks to protect process… Raynok is configurable, customizable, intuitive, creati ve and the only software tool you’ll need for controlling stage machinery. And of course Engineer The Art Of Movement for your production.

Type of Software:	Control Solution for stage and entertainment related machinery.
Developer:	Niscon Inc., Burlington, Ontario, Canada.
Applications:	Live Theatres, Concerts, Touring Productions, Television Studios, Circus Acts, Performer Flights, Animatronic Support, Museums, Sports Arenas, Night Clubs, Day Clubs, Kinetic Sculptures and more.
Versions / Models:	R2D for basic motion, R3D for 3D motion & Performer Flight.
Largest Installation:	327 hoists, 6 consoles, 1 server, 3 interlocked E-Stop Systems.
Largest Wireless Installation:	118 hoists, 5 consoles, 1 server.
Largest number of simultaneous Performer Flights:	14 (6 single lines, 8 multiple line).
External Connections and Data Transmissions:	Transmit position data, run commands or status information via, DMX via USB interface, DMX over ArtNET, PosiStageNet or our own External Command Manager via UDP.
Common Machines Controlled:	Wire Rope Hoists, Chain Hoists, Performer Hoists, Spiralift™, Serapid™, Hydraulics, Pneumatics, Rollers (curtains), Banners, Stage Lifts, Trolleys, Cable Reels, and so much more.
Training:	1 to 2 days basic operation, 4 to 5 days Performer Flight, 1 to 2 days maintenance and support, 2 add-on days for train the trainer.

For other models or more information, please visit https://www.raynok.com/

MAKE YOUR PROJECT A REALITY.
We tailor-make everything 100% to meet your needs. Contact our representatives for your quote.
