GALLERY MOUNTED
The locking rail supports Rope Locks and the write-on
strips to identify linesets.
Rope locks are mounted to a 2"X 3" X 5⁄16" angle iron
while the Write-on strip is mounted at an angle for
easy viewing.
The locking rail is constructed to withstand a 500 lbs
per linear foot (744.5 kg/m) up-load (Recommended
Weight Limit).
The Write-on strip can be written on using an erasable
marker or grease pencil.
The locking rail mounts to the edge of a counterweight
pit or gallery. Mounting method must be able
to withstand the imposed load.
Mounting stanchions are located on 5' (1.52m) (maximum)
centers and made from 2"X 3" X 5⁄16" steel
angle.
